TPE for
Construction
Flexible SEBS/SBS-based TPE compounds for construction mechanical parts - profile seals, gaskets, expansion-joint inserts, grommets, and anti-slip pads. Compliance-critical applications need qualification to the relevant standard.
15-90A / 40-52D
Shore hardness
range
40+
Farrprene
grades
100%
Recyclable &
reprocessable
Custom
Colour
matched
OUR MISSION
We engineer flexible, recyclable TPE compounds for construction sealing and mechanical parts, matched to your hardness and processing requirements.
01
Recommended grades
Suggested FARRPRENE compounds for this sector, matched by hardness and processing. Open a grade for its full datasheet.
| GRADE | HARDNESS | TYPE | TENSILE | TYPICAL USE |
|---|---|---|---|---|
| FARRPRENE EU401A | 40 Shore A | Extrusion / Unfilled | 6.5 MPa | Soft compression gaskets and glazing seals (extrusion) |
| FARRPRENE EF455A | 45 Shore A | Extrusion / Filled | 6 MPa | Window/door weather seals - low flow for stable profiles (extrusion) |
| FARRPRENE EF551AV | 55 Shore A | Extrusion / Filled | 5.5 MPa | Expansion-joint and profile seals (extrusion) |
| FARRPRENE EF651A | 65 Shore A | Extrusion / Filled | 7 MPa | Hard-wearing weatherstrip and gasket profiles (extrusion) |
| FARRPRENE IF752A | 75 Shore A | Injection / Filled | 5.5 MPa | Firm moulded spacers, end caps and fittings |
Typical average values, not a specification. Request the signed datasheet for current values, and ask us to qualify a compound to your exact requirement.
OVERVIEW
In construction, thermoplastic elastomers are used for extruded sealing profiles, glazing gaskets, expansion-joint seals and waterproofing components: parts that must compress against a mating surface, recover, and keep doing so through thermal movement. TPE profiles are extruded rather than cured, so they can be produced continuously, welded at corners and reprocessed. FARRPRENE extrusion grades cover the soft compression band used for glazing and weather seals through to firmer grades for moulded spacers and fittings.
KEY TAKEAWAYS
- Extruded TPE profiles are produced continuously and can be corner-welded, unlike cured rubber sections that must be vulcanised.
- Compression seals generally use the softest band that still recovers under the joint's working load.
- UV-stabilised grades are the starting point for any externally exposed profile.
- Fire performance and structural sealant compatibility are not characterised in the published catalogue and require separate qualification.
02
Hardness selection
Typical Shore A bands by part type. Selection guidance, not a specification - confirm against your own duty cycle. Rigid Shore D grades are a separate range.
| PART TYPE | TYPICAL BAND | WHY |
|---|---|---|
| Glazing gaskets and soft compression seals | 20-45 Shore A | Low compression force keeps glass and frame loads down while still filling the gap. |
| Window and door weather seals | 45-60 Shore A | Balances sealing compliance against the stiffness an extruded lip needs to hold shape. |
| Expansion-joint and movement seals | 50-65 Shore A | Must accommodate cyclic movement without taking a permanent set. |
| Hard-wearing weatherstrip and gasket profiles | 60-70 Shore A | Better abrasion resistance where the seal wipes against a moving surface. |
| Moulded spacers, end caps and fittings | 70-85 Shore A | Dimensional stability under load with residual flexibility for fitting. |
FREQUENTLY ASKED
Questions
engineers ask.
Are TPE seals suitable for outdoor construction use?
- UV-stabilised grades are formulated for external exposure and are the correct starting point for any profile that sees sunlight. Real service life depends on the exposure, the colour and the section geometry, so an outdoor profile should be qualified against its actual duty cycle rather than assumed from the datasheet.
What hardness is used for a glazing gasket?
- Glazing and compression gaskets typically use 20 to 45 Shore A. The design target is the softest compound that still recovers fully under the working compression, because a softer seal transmits less load into the glass and frame.
Can TPE profiles be welded at corners?
- Yes. Because thermoplastic elastomers re-melt, extruded profiles can be heat-welded at corners and joints, which is not possible with vulcanised rubber sections.
Do FARRPRENE grades carry a fire rating?
- No fire or flammability rating is published for the standard catalogue. Applications with a flame-retardancy requirement such as UL 94 or a building-code classification need a separately formulated and tested compound. Contact us to qualify one.
Can FARRPRENE grades be colour-matched?
- Yes. Unfilled (translucent) grades give the cleanest colour reproduction and are the usual base for a colour match to a customer reference. Filled (natural) grades can also be pigmented, with a slightly more muted result.
CONSTRUCTION TPE
Building better with
precision polymers.
Our engineering team develops construction-grade TPE compounds tailored to your sealing, insulation, and durability requirements.
